CPU
LGA1200 PACKAGE:
11TH GENERATION INTEL? CORE. I9 PROCESSORS / INTEL? CORE. I7 PROCESSORS /
INTEL? CORE. I5 PROCESSORS
10TH GENERATION INTEL? CORE. I9 PROCESSORS / INTEL? CORE. I7 PROCESSORS /
INTEL? CORE. I5 PROCESSORS / INTEL? CORE. I3 PROCESSORS/ INTEL? PENTIUM?
PROCESSORS / INTEL? CELERON? PROCESSORS
L3 CACHE VARIES WITH CPU
(PLEASE REFER TO "CPU SUPPORT LIST" FOR MORE INFORMATION.)
CHIPSET
INTEL? H470 EXPRESS CHIPSET
MEMORY
11TH GENERATION INTEL? CORE. I9/I7/I5 PROCESSORS:
SUPPORT FOR DDR4 3200/3000/2933/2666/2400/2133 MHZ MEMORY MODULES
10TH GENERATION INTEL? CORE. I9/I7 PROCESSORS:
SUPPORT FOR DDR4 2933/2666/2400/2133 MHZ MEMORY MODULES
10TH GENERATION INTEL? CORE. I5/I3/PENTIUM?/CELERON? PROCESSORS:
SUPPORT FOR DDR4 2666/2400/2133 MHZ MEMORY MODULES
2 X DDR4 DIMM SOCKETS SUPPORTING UP TO 64 GB (32 GB SINGLE DIMM CAPACITY) OF
SYSTEM MEMORY
DUAL CHANNEL MEMORY ARCHITECTURE
SUPPORT FOR ECC UN-BUFFERED DIMM 1RX8/2RX8 MEMORY MODULES (OPERATE IN NON-ECC
MODE)
SUPPORT FOR NON-ECC UN-BUFFERED DIMM 1RX8/2RX8/1RX16 MEMORY MODULES
SUPPORT FOR EXTREME MEMORY PROFILE (XMP) MEMORY MODULES
(PLEASE REFER "MEMORY SUPPORT LIST" FOR MORE INFORMATION.)
ONBOARD GRAPHICS
INTEGRATED GRAPHICS PROCESSOR-INTEL? HD GRAPHICS SUPPORT:
1 X HDMI PORT, SUPPORTING A MAXIMUM RESOLUTION OF 4096X2160@30 HZ
* SUPPORT FOR HDMI 1.4 VERSION AND HDCP 2.3.
1 X D-SUB PORT, SUPPORTING A MAXIMUM RESOLUTION OF 1920X1200@60 HZ
* THE D-SUB PORT IS ONLY AVAILABLE WITH THE 10TH GENERATION PROCESSORS.
(GRAPHICS SPECIFICATIONS MAY VARY DEPENDING ON CPU SUPPORT.)
AUDIO
REALTEK? AUDIO CODEC
HIGH DEFINITION AUDIO
2/4/5.1/7.1-CHANNEL
* YOU CAN CHANGE THE FUNCTIONALITY OF AN AUDIO JACK USING THE AUDIO SOFTWARE.
TO CONFIGURE 7.1-CHANNEL AUDIO, ACCESS THE AUDIO SOFTWARE FOR AUDIO SETTINGS.
LAN
REALTEK? GBE LAN CHIP (1 GBPS/100 MBPS/10 MBPS)
EXPANSION SLOTS
CPU:
1 X PCI EXPRESS X16 SLOT, SUPPORTING PCIE 3.0 AND RUNNING AT X16
CHIPSET:
1 X PCI EXPRESS X1 SLOT, SUPPORTING PCIE 3.0 AND RUNNING AT X1
STORAGE INTERFACE
CHIPSET:
1 X M.2 CONNECTOR (SOCKET 3, M KEY, TYPE 2280 SATA AND PCIE 3.0 X4/X2 SSD
SUPPORT)
4 X SATA 6GB/S CONNECTORS
RAID 0, RAID 1, RAID5, AND RAID 10 SUPPORT FOR NVME SSD STORAGE DEVICES
RAID 0, RAID 1, RAID5, AND RAID 10 SUPPORT FOR SATA STORAGE DEVICES
USB
CHIPSET:
4 X USB 3.2 GEN 1 PORTS (2 PORTS ON THE BACK PANEL, 2 PORTS AVAILABLE THROUGH
THE INTERNAL USB HEADER)
6 X USB 2.0/1.1 PORTS (4 PORTS ON THE BACK PANEL, 2 PORTS AVAILABLE THROUGH THE
INTERNAL USB HEADER)
INTERNAL I/O CONNECTORS
1 X 24-PIN ATX MAIN POWER CONNECTOR
1 X 8-PIN ATX 12V POWER CONNECTOR
1 X CPU FAN HEADER
1 X SYSTEM FAN HEADER
1 X RGB LED STRIP HEADER
1 X M.2 SOCKET 3 CONNECTOR
4 X SATA 6GB/S CONNECTORS
1 X FRONT PANEL HEADER
1 X FRONT PANEL AUDIO HEADER
1 X USB 3.2 GEN 1 HEADER
1 X USB 2.0/1.1 HEADER
1 X TRUSTED PLATFORM MODULE HEADER (FOR THE GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0
MODULE ONLY)
1 X SERIAL PORT HEADER
1 X CLEAR CMOS JUMPER
BACK PANEL CONNECTORS
1 X PS/2 KEYBOARD/MOUSE PORT
1 X D-SUB PORT
1 X HDMI PORT
2 X USB 3.2 GEN 1 PORTS
4 X USB 2.0/1.1 PORTS
1 X RJ-45 PORT
3 X AUDIO JACKS
